BLACKVUE DR750X 3 CHANNEL DMS PLUS | 18 BULAN GARANSI RESMI | HARGA BARANG SAJA
DR750X-3CH DMS Plus adalah kamera dasbor Cloud tiga saluran dengan kamera pemantauan driver tujuan khusus (DMC100).
Baik kamera depan maupun belakang menggunakan sensor gambar Full HD Sony STARVIS™ bercahaya belakang untuk kualitas gambar terbaik di bawah cahaya apa pun.
Kamera Pemantau Pengemudi inframerah merekam dan mendeteksi tanda-tanda kantuk atau lalai mengemudi dan memberi tahu Anda secara real time.
Dukungan cloud melalui hotspot Wi-Fi atau modul LTE plug-in USB opsional.
Kamera Pemantau Pengemudi
Kamera Pemantau Pengemudi inframerah (DMC100) dirancang untuk meningkatkan keselamatan pengemudi dengan membantu mencegah perilaku mengemudi yang berisiko. DMC100 memantau pengemudi setiap saat. Algoritmanya dapat mendeteksi status seperti:
- Mengemudi yang terganggu
- Mengantuk mengemudi
- Driver terdeteksi/tidak terdeteksi
Segera setelah situasi yang berpotensi berbahaya terdeteksi, DMC100 mengeluarkan bunyi bip untuk mengingatkan pengemudi dan memicu pemberitahuan push jika terhubung ke Cloud.
Spesifikasi :
Model Name DR750X-3CH DMS Plus
Channel 3CH
Highlights Full HD + Full HD + HD (Front + Rear + Interior), Cloud, Wi-Fi, GPS, Dual Sony Sensors, External LTE Module
Product Dimensions Front: Black / W 118.5 mm (4.67″) x H 36 mm (1.42″) / 105 g (3.70 oz)
Rear: Black / W 67.4 mm x H 25 mm / 25 g (0.88 oz)
DMS: Black / L: 113.5mm x W 66.4 mm x H 38.4mm / 139 g (4.90 oz)
Rear Camera Connection Coaxial cable
Memory Support microSD card up to 256GB
Recording Modes – Normal,
– Event (Impact Detection / Speed Limit / Manual),
– Parking Mode (Impact+Region-based Motion Detection, Timelapse+Events)
Parking Mode YES (with 3-wire hardwiring cable – included)
Parking Mode Event Voice Notifications YES
Imaging Sensor Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
DMS: CMOS Sensor (Approx. 1M Pixel)
Viewing Angle Front : Diagonal 139°, Horizontal 116°, Vertical 61°
Rear : Diagonal 139°, Horizontal 116°, Vertical 61°
DMS : Diagonal 54°, Horizontal 43°, Vertical 32°
Resolution Frame Rate Front / Rear / DMS
Full HD (1920×1080) @ 60 fps – Full HD @ 30 fps (1920×1080) – HD (1280×720) @ 10 fps
*Frame rate may vary during Wi-Fi streaming.
Video Codec H.264 (AVC)
Image Quality and Bitrate Front/Rear Front / Rear / Interior
Highest (Extreme): 16 + 10 + 8 Mbps
Highest: 12 + 10 + 8 Mbps
High: 10 + 8 + 6 Mbps
Normal: 8 + 6 + 4 Mbps
Format Free YES (Adaptive)
Event File Overwrite Protection YES (up to 50)
SD Card Failure Alert YES
Scheduled Reboot YES
Video File Extension MP4
Wi-Fi Built-in (802.11 b.g.n)
Cloud Compatible YES
GPS Built-in (Dual Band : GPS, GLONASS)
Microphone Built-in
Speaker Built-in
Impact Sensor 3-Axis Acceleration Sensor
LED Indicators Front: Recording LED, GPS LED, B/W/L LED, Front Security LED
Rear: Rear Security LED
DMS: Status LED
Rear Camera IR Illumination Interior USB: 940 nm (4 Infrared (IR) LEDs)
Button Button: Wi-Fi ON/OFF (Press)
Proximity sensor: Mic ON/OFF / Trigger Manual Recording / OFF (configurable)
Operation Temperature -20 °C − 70 °C (-4 °F − 158 °F)
Storage Temperature -20 °C − 85 °C (-4 °F − 185 °F )
High Temp Cut Off Approx. 75 °C (167 °F )
Backup Battery Built-in supercapacitor
Input Power DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)
Power Consumption Hour Normal Mode (WiFi On / GPS On / 3CH): Avg. 670mA / 12V
Normal Mode (WiFi Off / GPS On / 3CH): Avg. 630mA / 12V
Parking Mode (WiFi On / GPS Off / 3CH): Avg. 370mA / 12V
Parking Mode (WiFi Off / GPS Off / 3CH): Avg. 320 mA / 12V
* Actual power consumption may vary depending on use conditions and environment.
* Approximately, 60mA may increase in electric current when IR LED is turned ON.
Certifications Front: FCC, ISED, CE, UKCA, RoHS, Telec, WEEE
Rear: FCC, ISED, CE, UKCA, RoHS, WEEE
DMS: FCC, CE, UKCA, RoHS, WEEE
software BlackVue Viewer
* Windows 7 or higher and Mac OS X Sierra v10.12 or higher
Application BlackVue Application (Android 5.0 or higher, iOS 11.0 or higher)
Others Adaptive Format-Free File Management System
Bluetooth Built-in (V2.1+EDR/4.2)
LTE External (optional)
