PROCESSOR ZAPCO ADSP-Z8 IV-8 | NEW PRODUK!!! | AMERICAN TECHNOLOGY
SPESIFIKASI :
DSP Processor: Cirrus Logic CS47048
Power: 150 MHz/32 bit/48 KHz
8-Channels
ADC: Cirrus Logic CS5368 24 bit/192 KHz
ADC Dynamic Range/THD: 114 dB/-105 dB
DAC: Cirrus Logic CS47048 32 bit/192 KHz
DAC Dynamic Range/THD: 108 dB/-98 dB
Low level (Pre)/Sensitivity: 8/1-5 VRMS
High Level (Spk In)/Sens.: 6/2-20 V
AUX Inputs/Sensitivity: 1/0.2-4 VRMS
Optical IN: 24 bit-192 KHz
Freq. Response (-3dB): 10 Hz – 22.5 KHz
S/N Ratio only DSP Digital Input: 110 dBA
S/N Ratio only DSP Analog Input: 106 dBA
S/N Ratio Amp + DSP at max. power: 95 dBA
THD+N only DSP Digital Input: 0,002 %
THD+N only DSP Analog Input: 0,005 %
THD+N Amplif. + DSP Analog Input: 0,07 %
Crosstalk at 1 Khz only DSP: 90 dB
Crosstalk Amplifier + DSP: 45 dB
Amp Power @ 4Ω: 8 x 80 watts
Amp Power @ 2Ω: 8 x 120 watts
Amp Power @ 4Ω Bridged: 4 x 240 watts
Amp Power @ 4Ω: 6 x 80 + 1 x 240 watts
Amp Power @ 2Ω: 6 x 120 + 1 x 240 w. (4 Ω)
F/R EQ: 1-6 ch Gr. & Par./31 poles
Effect EQ: 7-8 ch Gr. & Par./11 poles
Mute/Solo: Yes, each channel
Time Align. (Range/Steps): 0/15 ms / 0.02 ms
Max Delay (Cm/Steps): 515 cm / 0.68 cm
Polarity: 0/180°
Display (included): 1” LCD
Display (optional): 3” LCD Touch-Screen
Bluetooth Digital Streaming
PC/Display Connection: USB/6-pin Mini DIN
Unit Dimensions: 222(L) x 230(W) x 52(H)
