Venom VX 8.2A DSP – Subwoofer Aktif Kolong Jok 8 Inch Built in DSP
Subwoofer 8 inch + processor
Processor 8 ch built in 4 ch power amplifier
Power Supply
– Voltage: 11-15 VDC
– Idling current: 0.4 A
– Switched off without DRC: 2.5 mA
– Switched off with DRC: 4 mA
– Remote IN voltage: 1-15 VDC (1.3 mA)
– Remote OUT voltage: 12 VDC (130mA)
Power Output
– Effective power: 4 x 25W +1 x 200W
– Peak Power: 4 x 75W + 1 x 500W
Signal Stage
– Distortion – THD @1kHz, 1V RMS Output: 0.05%
– Bandwith @ -3dB : 10 -22k Hz
– Master input: 95dBA
– Channel separation @ 1 kHz : 88dB
– Input sensitivy (High Level) : 2 -15 V RMS
– Max Output Level (RMS) @ 0.1% THD : 2 V RMS
Input Stage
– High Level (Speaker) : FR- FR+ FL- FL+ RL- RL+ RR- RR+
Output Stage
– Low level: CH7 CH8
Crossover N.5 (each output channel)
– Fillter Type : FULL / HIGH PASS / LOW PASS / BAND PASS
– Stope Setting : 6 / 12 / 18 / 24 / 30 / 36 / 42 / 48 dB
– Crossover Frequency: 68 steps @ 10 -20k Hz
– Phase control independently set to each channel: 0° – 180°
– Time delay independently set to each channel : 0 – 15 MS
