Mosconi 8 To 12 Aerospace Hi Res | Harga Barang Saja | 1 Tahun Garansi Resmi
Technical Specifications:
INPUT MODE: Low Level (LL) / High Level (HL)
INPUT IMPEDANCE: > 12KOhm (LL) / 47Ohm (HL)
INPUT SENSITIVITY: 1.2Vrms ÷ 8Vrms (LL) / 3Vrms ÷ 20Vrms (HL)
INPUT VOLTAGE REGULATION: -16.5dB ÷ 0dB
MAX OUTPUT SIGNAL: 8Vrms
OUTPUT IMPEDANCE: 600 Ohm
THD DISTORTION: <0.003% @ 4Vrms
FREQUENCY RESPONSE: 10Hz ÷ 63KHz (within -0.1dB)
CHANNEL SEPARATION: >90dB (@ 1KHz)
SUPPLY VOLTAGE: 11V ÷ 15V
CURRENT CONSUMPTION: 0.9A @ 12V
AUTOSENSE: OFF / BTL / SE
REMOTE OUTPUT: 100mA max.
COMMUNICATION PERIPHERALS: USB,RCD/RC-MINI (optional), MOS-BTM (optional)
SIZE: 200 x 125 x 40 mm (including fixing feet)
