JL AUDIO 12W0V3-4 | HARGA BARANG SAJA | 1 TAHUN GARANSI RESMI
SPESIFIKASI :
Continuous Power Handling (RMS) 300 W
Recommended Amplifier Power (RMS) 75 – 300 W
Nominal Impedance (Znom) 4 Ω
Nominal Diameter 12.0 in / 300 mm
Overall Diameter (A) 12.52 in / 318 mm
Mounting Hole Diameter (B) 11.0625 in / 281 mm
Bolt Hole Circle Diameter (C) 11.7 in / 297 mm
Motor Outer Diameter (D) 5.05 in / 128 mm
Mounting Depth (E) 5.40 in / 137 mm
Driver Displacement 0.048 cu ft / 1.36 L
Net Weight 8.11 lb / 3.68 kg
Free Air Resonance (Fs) 28.43 Hz
Electrical “Q” (Qes) 0.715
Mechanical “Q” (Qms) 10.709
Total Speaker “Q” (Qts) 0.67
Equivalent Compliance (Vas) 2.530 cu ft / 71.64 L
One-Way Linear Excursion (Xmax)* 0.45 in / 11.4 mm
Reference Efficiency (no) 0.22%
Efficiency (1 W / 1 m)** 85.64 dB SPL
Effective Piston Area (Sd) 74.509 sq in / 0.0481 sq m
DC Resistance (Re) 4.280 Ω
