JL AUDIO 10W0V3-4 | HARGA BARANG SAJA | 1 TAHUN GARANSI RESMI
SPESIFIKASI :
Continuous Power Handling (RMS) 300 W
Recommended Amplifier Power (RMS) 75 – 300 W
Nominal Impedance (Znom) 4 Ω
Nominal Diameter 10.0 in / 250 mm
Overall Diameter (A) 10.52 in / 267 mm
Mounting Hole Diameter (B) 9.0625 in / 230 mm
Bolt Hole Circle Diameter (C) 9.7 in / 246.5 mm
Motor Outer Diameter (D) 5.05 in / 128 mm
Mounting Depth (E) 4.90 in / 124 mm
Driver Displacement 0.034 cu ft / 0.96 L
Net Weight 7.50 lb / 3.40 kg
Free Air Resonance (Fs) 32.09 Hz
Electrical “Q” (Qes) 0.64
Mechanical “Q” (Qms) 10.752
Total Speaker “Q” (Qts) 0.604
Equivalent Compliance (Vas) 1.095 cu ft / 31.01 L
One-Way Linear Excursion (Xmax)* 0.45 in / 11.4 mm
Reference Efficiency (no) 0.15%
Efficiency (1 W / 1 m)** 84.07 dB SPL
Effective Piston Area (Sd) 48.909 sq in / 0.0316 sq m
DC Resistance (Re) 4.280 Ω
