JBL Stage Amps are available in a variety of configurations, delivering the right power and number of channels for full-range and subwoofer applications. For more than four decades, JBL has made the audio experience a lot more satisfying for the car audio enthusiast. With a broad array of loudspeakers, amplifiers and subwooers available, you can drive with ease and exhilaration. These compact amps are equipped with all the important inputs and user controls including a bass EQ as well as LPF and HPF crossover controls for tailoring sound to suit the characteristics of different vehicles. The Stage Amps are easily installed and amazingly reliableand once they turn on, they’ll make a transducer sit up and sing.
Specification :
Operating voltage: 9 16V
RMS power @ 4 ohms: 90W
RMS power @ 2 ohms: 110W
RMS bridged power @ 4 ohms: 220W
Total peak power: 880W
Frequency response: 20Hz 20kHz @ -1dB
Signal-to-noise ratio: >75dB
Maximum high input signal level: 12V
High input maximum sensitivity: 0.5V
Maximum line input signal level: 5V
Line input maximum sensitivity: 0.2V
Quiescent current draw: <1.5A
Fuse size: 2 x 20A
Features :
Full On-Board Protection
Input Level Control
Switchable bass EQ
Compact footprint
