HELIX M ONE
TECHNICAL DATA :
- Output power RMS ≤ 1% THD+N
– @ 4 Ohms 1 x 240 Watts
– @ 2 Ohms 1 x 410 Watts
– @ 1 Ohm 1 x 600 Watts
– bridged @ 4 Ohms –
– bridged @ 2 Ohms – - Max. output power per channel* Up to 720 Watts RMS @ 1 Ohm
- Amplifier technology Class D
- Inputs 2 x RCA / Cinch
– 2 x Highlevel speaker input
– 1 x Remote In
– 1 x Remote control input - Input sensitivity
– RCA / Cinch 0.5 – 6 Volts
– Highlevel 1.1 – 13 Volts - Input impedance RCA / Cinch 20 kOhms
- Input impedance highlevel 13 Ohms
- Outputs 1 x Speaker output
- Output voltage RCA / Cinch –
- Signal converter for digital input –
- Frequency response 10 Hz – 250 Hz
- Bass boost 0 – 12 dB / 25 – 75 Hz
- Highpass –
- Lowpass 50 Hz – 250 Hz adjustable
- Bandpass 10 Hz – 250 Hz adjustable
- Subsonic 10 Hz – 50 Hz adjustable
- Phase 0 – 180° adjustable
- Slope high- / lowpass –
- Slope subsonic / lowpass 12 / 24 dB/Oct.
- Signal-to-noise ratio digital input –
- Signal-to-noise ratio analog input 95 dB (A-weighted)
- Distortion (THD) 0.20 %
- Damping factor 100
- Operating voltage 10.5 – 16 Volts (max. 5 sec. down to 6 Volts)
- Idle current 650 mA
- Fuse 2 x 35 A Maxi-fuse (APX)
- Additional features Active, adjustable crossover, bass boost, phase shift, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), bass volume cable remote control
- Dimensions (H x W x D) 50 x 230 x 154 mm / 2.00 x 9.06 x 6.06”
