HELIX DSP ULTRA
SPECIAL FEATURE :
- RealCenter
- Augmented Bass Processing
- StageXpander
- ClarityXpander
TECHNICAL DATA :
- Inputs
8 x RCA / Cinch
8 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x Coax SPDIF (12 – 192 kHz)
1 x Remote In - Input sensitivity
RCA / Cinch 1 – 8 Volts
Highlevel 4 – 32 Volts - Outputs
12 x RCA / Cinch
1 x Remote Out - Output voltage 8 Volts
- Frequency response 10 Hz – 44,000 Hz
- DSP resolution 64 Bit
- DSP power 2 x 295 MHz (2.4 billion MAC operations/second)
- Sampling rate 96 kHz
- DSP type 2 x Audio signal processor
- Signal converters
A/D: Asahi Kasei 32 Bit
D/A: Asahi Kasei 32 Bit - Signal-to-noise ratio digital input 117 dB (A-weighted)
- Signal-to-noise ratio analog input 111 dB (A-weighted)
- Total harmonic distortion (THD+N) digital input < 0.0004 %
- Total harmonic distortion (THD+N) analog input < 0.001 %
- IM distortion (IMD) digital input < 0.002 %
- IM distortion (IMD) analog input < 0.004 %
- Crosstalk > 90 dB
- Operating voltage 9.6 – 18 Volts (max. 5 sec. down to 6 Volts)
- Power rating DC 12 V ⎓ 1.2 A max.
- Current draw 650 mA
- Max. remote output current 500 mA
- Additional features HEC slot, Ground lift switch, Control Input, 32 Bit CoProcessor, ADEP.3 circuit, Auto Remote switch
- Dimensions (H x W x D) 40 x 177 x 170 mm / 1.58 x 6.97 x 6.69“
